| Application/type |
Actuator |
| Purpose |
Room Climate Control, Lighting control, Shading control |
| Interface |
EnOcean (868 MHz), Switch contact |
| Output switch contact |
4x additional changeover contact |
| Operating range temperature (°C) |
0..+60 |
| Operating ranges temperature (°C) |
0..+60 |
| Operating range humidity |
max. 85% rH non-condensing |
| Enclosure |
ABS |
| Colour |
light grey |
| Protection (IP) |
IP20, according to EN 60529 |
| Connection |
terminal block, max. 1,5 mm² |
| Mounting |
prepared for mounting on DIN rail TS35 (35x7,5 mm) according to EN 60715 |
| Packaging length (mm) |
90 |
| Packaging width (mm) |
90 |
| Packaging height (mm) |
80 |
| Packaging |
case packaging |
| Device length (mm) |
53 |
| Device width (mm) |
90 |
| Device height (mm) |
60 |
| Weight (g) |
90 |
